SimpleVIS® is a single sample, portable viscometer for on-site testing. With near D445 precision, it is easy to use, rugged and fast. Available viscometer tubes cover a viscosity range of 2 mm2/s (cSt) to 700 mm2/s (cSt) at two selected temperatures between 40 °C and 100 °C

• Near ASTM D445 precision with temperature control +/- 0.05°C
• 40°C or 100°C user selectable
• Graphical touch screen
• No menus, no additional switches gauges or valves to adjust
• Factory Calibrated
• Smallest Capillary Viscometer on the Market
• Solid Bath (no liquid to spill)
• Fully self-contained(no external PC)
• Direct Kinematic Viscosity Measurement, no need to Correlate Dynamic Viscosity Data
• Modified Cross-Arm Style Tube,works with Both Transparent & Opaque oils
• Reliable: Only 2 Moving Internal Parts
• Easy to Use: Graphical Touch
• Small Sample Volume: 0.5 mL
• Rapid Cycle Time: ~ 3 min
• Applications:ISO VG Lubricants, SAE Engine and Gear Oils
• Methodology:Kinematic Viscosity, ASTM D7279 or ASTM D445-Modified
• Test Temperatures:40 or 100 °C - user selectable
• Viscosity Range:40°C: 10 – 700 mm2/s (cSt);100°C: 5.5 – 200 mm2/s (cSt)
• Accuracy:< 3% of measured value, calibrated
• Repeatability:< 2% of measured value, typical
• Sample Material Type:Mineral Oils, Synthetic Oils, Formulated Motor/Gear Oils
• Solvent Compatibility:Internal wetted components compatible with n-heptane only
