The HTHS Series II is a multicell capillary viscometer for simple viscosity testing of engine oils at high temperature and
high shear. It meets all requirements and precision specifications of ASTM D5481 and SAE J300.

Meets all ASTM D5481 and SAE J300 requirements and precision specifications
-- Temperature range: 30 °C to 150 °C (±0.1 °C)
-- Viscosity range: 2 mPa·s (cP) to 7 mPa·s (cP)*
-- Test pressure: variable from 75 psi to 500 psi
-- Variable test temperature and shear rate supports research applications
User-friendly, high speed testing
-- Simple, one-button operation
-- Multi-cell design permits sequential testing of up to 5 different samples
-- Tests up to 20 samples per hour at 1.4 x 106s-1 at 150 °C
-- Instrument digitally displays flow time, temperature and pressure
-- Standalone viscosity calculation software analyzes data and displays results
-- Sample flush cycle eliminates need for hazardous cleaning solvents
Robust, reliable performance
-- Proven CANNON® reliability and outstanding support
-- Reduced operator role enhances repeatability and reproducibility
