atten2’s OilWear® P120 is anonline sensor that quantifies particles larger than 14μ present in fluids, classifies them by size in 4 channels and measures the degradation of the fluid. This is a low cost sensor designed to be permanently installed on a machine, or to be installed on multiple machines, providing real-time information on contamination of fluids.

OilWear® P120 provides key information to carry out a predictive maintenance strategy. The measurement

of an abnormal amount of particles allows the detection of early stages of machine failure and implementation of

corrective actions.

OilWear® P120 has a fully modular design, and its measuring module, which is the main responsible for the counting

and classification of the particles, can be easily integrated into the oil Condition Monitoring System, simply ensuring minimum flow conditions in the oil that is monitored.

Classification of particles of over 14 μm depending on size.

Early information about oil degradation.

Low cost solution.

Plug & Play, the sensor offers a standard output with single plug.

Early information on the state of the machine is provided.

It prolongs the life of the fluids and cuts machine downtime.

It provides rapid, reliable information on the contamination of the fluids.

Full integration with SCADA/PC/PLC by means of analogue and digital communications.

Self-diagnosis, self-calibration and self-compensation.

Possibility of stipulating warning levels.

Possibility of stipulating the size ranges of the particles to be counted.

Possibility of integrating with OilHealthR, whereby a single sensor provides information on oil degradation and contamination.
